Specifications
Type: 2-speed, direct belt drive turntable with auto lift/stop
Platter: 12", 1.5kg, aluminium alloy die-cast
Motor: 4-pole synchronous
Speeds: 33 and 45rpm
Signal to noise ratio: better than 45dB
Wow and flutter: less than 0.06%
Tonearm: static balanced, gimbals supported tubular arm with anti-skating device, lateral balancer and direct readout tracking force weight
Effective length: 230mm
Overhang: 15mm
Tracking error: less than +-1.5 degree
Cartridge: induced magnet type
Frequency response: 20 to 20,000Hz
Output: 5mV
Crosstalk: better than 25dB
Optimum tracking force: 2.0g
Stylus: 0.5 mil diamond
Load resistance: 50k ohms
Dimensions: 198 x 505 x 370mm
Weight: 12kg
