Tuning range: FM, MW
Power output: 25 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 70kHz
Total harmonic distortion: 0.3%
Damping factor: 30
Input sensitivity: 3mV (MM), 150mV (line)
Signal to noise ratio: 80dB (MM), 90dB (line)
Channel separation: 50dB (MM)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4Ω to 16Ω
Dimensions: 480 x 128 x 268mm
Weight: 6.8kg
Power output: 45 watts per channel into 8Ω (stereo)
Frequency response: 5Hz to 70kHz
Total harmonic distortion: 0.05%
Input sensitivity: 2.5mV (MM), 150mV (line)
Signal to noise ratio: 75dB (MM), 95dB (line)
Output: 150mV (line)
Speaker load impedance: 8Ω (minimum)
Dimensions: 430 x 147 x 251mm
Weight: 6.3kg
Power output: 55 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 100kHz
Total harmonic distortion: 0.1%
Damping factor: 35
Input sensitivity: 2.5mV (MM), 150mV (line)
Signal to noise ratio: 70dB (MM), 90dB (line)
Output: 150mV (line), 17mV (DIN), 1V (Pre out)
Semiconductors: 4 x FET, 43 x transistors, 27 x diodes
Dimensions: 460 x 170 x 325mm
Weight: 12kg
Power output: 45 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 60kHz
Total harmonic distortion: 0.1%
Damping factor: 30
Input sensitivity: 3mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 75dB (MM), 95dB (line)
Channel separation: 55dB (MM)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4Ω to 16Ω
Semiconductors: 27 x transistors, 17 x diodes, 4 x IC
Dimensions: 440 x 144 x 345mm
Weight: 9.9kg
Finish: black, silver
Power output: 50 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.03%
Damping factor: 100
Input sensitivity: 0.12mV (MC), 2.6mV (MM), 170mV (line)
Signal to noise ratio: 78dB (MC), 80dB (MM), 97dB (line)
Dimensions: 420 x 95 x 350mm
Weight: 8.9kg
Year: 1995
Tuning range: FM, MW
Power output: 60 watts per channel into 8Ω (stereo)
Frequency response: 5Hz to 50kHz
Total harmonic distortion: 0.03%
Damping factor: 50
Input sensitivity: 6mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 78dB (MM), 95dB (line)
Channel separation: 55dB (MM), 65dB (line)
Output: 150mV (line), 43mV (DIN)
Speaker load impedance: 8Ω (minimum)
Dimensions: 464 x 181 x 408mm
Weight: 12.8kg
Power output: 40 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.08%
Year: 1979
